100L Heavy Lift Agricultural Spraying Drone

Key Features
Large Capacity & Dual-Function Tank: A 100L liquid tank supports extended operations, while the integrated design enables both liquid spraying and solid spreading (e.g., fertilizer pellets), enhancing versatility.
High-Efficiency Spraying System: Equipped with 4 centrifugal nozzles, it achieves a spray width of 8-15m and a flow rate of 24L/min, with atomized droplets (30-500μm) for optimal coverage.
Advanced Navigation & Safety: Integrates GPS/BDS/Glonass positioning, dual obstacle avoidance radars, and terrain-following radar (adapting to gradients up to 45°), ensuring stable flight even in complex environments.
Durable & User-Friendly Design: IP67 waterproof rating protects against dust and water, while foldable propellers (33503350990mm when folded) facilitate transportation. It also includes free online training for easy operation.

Application Scenarios

• Large-Scale Farmland Spraying: Efficiently applies pesticides, fertilizers, and herbicides across vast fields (e.g., wheat, corn, and rice plantations), reducing manual labor and ensuring uniform coverage.
• Orchard Operations: Navigates through dense fruit tree canopies (such as apple, citrus, and pear orchards) to target foliage precisely, minimizing chemical waste and protecting crop health.
• Pest Control & Disinfection: Capable of night operations with high-brightness lights, it effectively combats nocturnal pests and performs large-area disinfection in agricultural zones.
• Diverse Crop Adaptability: Suitable for both low-lying crops (e.g., vegetables) and tall-stem plants (e.g., sugarcane), adapting to varying terrain and crop heights via terrain-following radar.

Do Large-Capacity Agricultural Drones Outperform Small Ones in Efficiency?
Vast Area Coverage Advantage
Large-capacity drones shine in covering extensive farmland quickly. Their larger tanks hold more pesticides, allowing them to spray for longer periods without frequent refills. In a typical operation, a large drone can tackle dozens of acres in a single flight, ideal for sprawling wheat fields or corn plantations. This capability reduces the time spent on repeated takeoffs and landings, making large-scale spraying far more efficient than small drones that require constant reloading.
Streamlined Operation for Big Farms
For commercial farming operations, large-capacity drones simplify workflow management. Operators can program them to cover vast areas with minimal intervention, eliminating the need to coordinate multiple small drones. In a soybean ranch, a single large drone can complete spraying over extensive areas in a fraction of the time small drones would take. The unified control system of large drones also ensures consistent spraying parameters across the entire field, maintaining uniformity in pest control.
Energy-Efficient for Extensive Use
Large-capacity drones offer better energy efficiency for large-scale applications. While their initial investment is higher, they require fewer units to service large farms-for example, one large drone can replace several small ones on a 100-acre farm, reducing equipment costs and operational complexity. Additionally, their optimized battery systems maximize flight time per charge, allowing them to cover more acres efficiently. This makes large drones a practical choice for farmers managing extensive land, balancing energy use with high-performance spraying.

Large Capacity
The 100L liquid tank provides a substantial payload, reducing the need for frequent refilling and enhancing operational efficiency.
Spraying and Spreading
Designed to handle both liquid spraying and solid spreading tasks, this drone maximizes versatility for diverse agricultural operations.
Large Medication Port
The wide-opening design of the medication port allows for quick and convenient filling, minimizing downtime during pesticide/fertilizer loading.

High-Efficiency Atomization
Centrifugal nozzles produce uniform droplets (30-500μm) for precise pesticide application, ensuring optimal coverage and reducing waste.
Wide Spray Width
With an 8-15m spraying range per nozzle, the system minimizes flight passes and increases operational efficiency.
Adjustable Flow Rate
The centrifugal design allows variable flow control, adapting to different crop types and treatment requirements.

Single-Axis Gimbal Stability
The camera’s single-axis gimbal minimizes vibration and ensures smooth footage during flight, enhancing observation accuracy.
Wide Adjustable Pitch Angle
With a -90° to 20° pitch range, the camera offers flexible viewpoints for inspecting crops, terrain, or infrastructure.
High-Brightness Night Navigation Lights
Integrated night flight lights enable safe low-light operations and visual positioning in dark environments.

Dual-Pump Redundancy
Two high-flow pumps ensure continuous operation even if one pump fails, enhancing reliability during critical spraying tasks.
High-Flow Performance
With a maximum flow rate of 24L/min, the pumps deliver rapid liquid distribution for efficient coverage over large areas.
External Filter Protection
Integrated external filters prevent debris from entering the pumps, reducing maintenance needs and extending equipment lifespan.

Dual Obstacle Avoidance Radars
Two radars provide 360° environmental awareness, detecting obstacles in all directions to prevent collisions during low-altitude operations.
Terrain-Following Radar
Automatically adjusts flight altitude according to ground topography, ensuring consistent spraying/spreading heights over uneven terrain.
 High-Speed Obstacle Response
Capable of detecting obstacles at speeds ≤8m/s and maintaining ≥2m safety distance, enabling safe operations in dynamic environments.

Advantages
Time & Cost Efficiency: With a maximum work efficiency of 35 hectares per hour, significantly reducing labor costs and operational time.
Precision & Resource Savings: Adjustable flow rates and uniform atomization minimize chemical usage by 20-30% compared to traditional methods, lowering environmental impact.
Reliability & Adaptability: Dual pumps and redundant battery systems (18S 30000mAh*2) ensure uninterrupted operation, while night flight capabilities and all-weather design extend working hours.
Scalability for Large Farms: Eliminates the need for multiple small drones, as one unit can service 100+ acre farms, simplifying management and reducing equipment investment.
