Backpack Weeder Robot

Product Highlights

• All-Terrain Capability: Supports 55-60 degree tilt angles with enlarged rubber tracks for extreme terrain.
• Dual-Speed Hydraulic Drive: French hydraulic motors offer 4 km/h low speed and 8.6 km/h high speed.
• Powerful Diesel Engine: Yanmar 3-cylinder engine delivers 28.2KW (40HP) with 0-3000rpm header speed.
• Extended Warranty Options: Standard 12-month warranty available with optional coverage up to 36 months.
• Global After-Sales Support: 24/7 technical assistance and spare parts supply with overseas service centers.
• Customizable Configurations: Tailored attachments and custom configurations available upon request.
• Smart Remote Control: 200m wireless range with automatic parking and continuous speed adjustment.
• Efficient Cooling System: Customized oil-water integrated system with optional bidirectional fan cleaning.

Weeding Robot

All-terrain remote-controlled hydraulic platform
Meaning of the name
All-terrain: Highly adaptable, excellent traversability
Remote control: Wireless technology, remote operation
Hydraulics: Refers to the transmission method under the action of oil fluid.
Platform: Capable of supporting multiple functions.

Product characteristics

 Configuration

Yuhama 3-cylinder 4-stroke water-cooled direct injection engine
28.2KW diesel engine, with a maximum horsepower of approximately 40 horsepower and a maximum rotational speed of less than 3200 rpm.
2. Imported hydraulic system from Italy, electro-hydraulic proportional servo system
Original imported hydraulic pump
3. Dual-drive walking with hydraulic motors, French walking motor
The motor is equipped with a dual-speed system, automatic parking and remote parking. The maximum speed at low speed is 4 km/h, and the maximum speed at high speed is 8.6 km/h. Through remote control, the machine can easily adapt to different working environments, making the operation more convenient and efficient. The low-speed range supports continuous speed adjustment from 0 to the maximum speed.
4. Supports a maximum tilt angle of 55-60 degrees in all directions.
5. Independently developed bidirectional fan system, supporting regular cleaning and forced cleaning of the cooler cover (optional)
6. Enlarged tooth rubber tracks, providing excellent grip in extreme angles of operation
7. Cooling System
Customized oil-water integrated cooling system, enabling effective heat dissipation in any environment permitted by the machine.
8.Hydraulic Components Hydraulic hose. Pipeline connector. Quick connector for oil pipe (Spain). Fuel tank filter. Cylinder assembly. Electromagnetic valve assembly

Technical Specifications

(Custom configurations available upon request.)

Overall dimensions:	2*1.4*1.2m
With header:	2.8*1.4*1.2
Weight:	1.2 tons
With header:	1.36
Header dimensions:	1.4*0.8*0.56m
With header:	160kg
Power:	Yanmar 3I4 4-stroke water-cooled direct injection engine
Power output:	28.2KW, 40HP
Travel motor:	French
Speed:	[Low speed 4km/h – High speed 8.6km/h]
Maximum tilt angle:	55-60°
Remote control and sensors:	200m
Remote control frequency:	433
Header speed:	0-3000rpm

After Sales Service

Standard Warranty: 12 months or 2,000 operating hours (whichever comes first).
Extended Warranty: Optional coverage up to 36 months.
Global Support: 24/7 technical assistance and spare parts supply.
Training: On-site or remote operation/maintenance training.
