4X4 Farm Tractor with Front Loader and Backhoe

Yaweh 4X4 Farm Tractor with Front Loader and khoe

Production Capacity

2000 Sets / Year

Packaging & Delivery

Package Size

500.00cm * 480.00cm * 400.00cm

Package Gross Weight

8000.000kg

Product Description

1. Luxury enlarged cab, luxury seat , Cab with hydraulic forward tilting function, easy maintenance.

2. The top canopy of the cab can be removed for container delivery.

3. Streamline enlarged fuel tank with tilting oil port, easy to refill

4. Hydraulic componentes use famous brand , with long working life and stable performance; oversize water tank, high-temperature resistant;

5. Large radiator suitable for very hot area.

6. Hydraulic steering system , easy to control

7. Hydraulic walking,with Chinese best torque converter,contiuously variable transmission;Service brake is air over hudraulic discc brake on 4 wheels, with blast pump.

8. It have all the functions of 180°wheel excavator and the same wheel loader.

9. Excellent operating performance with high working efficiency

10. All kinds of attachments are optional,such as snow blade,road sweeper,hydraulic hammer,grapple, pallet fork, to meet different customer’s requirement.

11.Can equipped with ROPS cabin as optional.

12.Can equipped with Air conditioner,break hammer,4in 1 bucket,6 in 1 bucket,quick hitch and pre-breaking line as optional.

You know what difference about our khoe loaders?

– Our backhoe loaders deliver the power and precise handling you need when operating in areas where using larger equipment is not practical. Because of their relatively small frame size and versatility our backhoe loaders improve construction productivity and lower your machine operating costs.

– Our backhoe loaders were designed as a system, which means every part plays a critical role. It’s why we’ve made it easier to maintain your machine.

– The shape of our buckets improves digging, loading and material retention.

We Pay More Attention To Details, Details Are Our Quality

1. It has excellent work efficiency and cost performance.

2. The standard bulldozer can level the site and backfill the earth to increase the stability of the machine.

3. Simple, small and flexible, easy to transport, can work in small sites, especially suitable for orchards, such as kiwi, vineyards, oranges, navel oranges, digging trenches, fertilizing, and weeding.

4. It has multiple functions of mining, crushing, removing hooks, drilling, and earthwork, and can quickly replace accessories,greatly improving the utilization rate of the machine.

What are the advantages of our khoe Loader?

Advantages of our khoe Loader: support multi-function operation, fast attachment of accessories, excavation, crushing, trench cleaning, drilling and bulldozing;

Yaweh 30-25 khoe Loader
Overall size		Engine
Dimension(mm)	580022683760	Model	YuDong 4105 Supercharged
Wheelbase(mm)	2370	Type	Turbocharged
Wheeltrack (mm)	1640	Rated Power (KW)	85
Min Ground Clearance (mm)	300	Rated speed(r/min)	2400
Min. turning radius(mm)	5000	Number of cylinders – bore	4-105
Performance Parameters		Transmission system
System Pressure (Mpa)	28	Transmission	Fixed-axis powershift
Weight (kg)	7650	Number of gears	Front 2 and back 2
Max Speed (Km/h)	22	Torque converter	YJ280
Max. climbing capacity	35
Excavation parameters		Steering system
Max. digging depth(mm)	4000-5200	Type	Articulated fully hydraulic steering
Max. digging radius(mm)	5880/7000	Steering angle(°)	36
Max. unloading height(mm)	4200/5000	Axle
Hopper capacity(mm)	0.3	Type	Wheelside reduction bridge
Excavator slewing angle(°)	190
Loading parameters		Tires
Max. unloading height(mm)	2770	Specification	16/70-20
Max. unloading distance(mm)	925	Travel brake	Air top oil caliper disc brake
Loading bucket capacity(m³)	1	Parking brake	Handbrake
Rated loading capacity	2500	Other
Oil volume		Drive type	Four-wheel drive
Fuel Tank(L)	60	Variable speed form	Hydraulic variable speed
Hydraulic oil tank(L)	60	Operating System	Electromagnetic hydraulic pilot control

Why Choose Us?

Quality
Yaweh Heavy Industries utilize only quality, proven componentry in the production of our product range.

All Yaweh Machinery undergoes rigorous factory testing for both operation and finish prior to delivery.

Warranty
The premium range of Yaweh products is supported by a no nonsense 12 month / 2000 hour parts warranty. We will replace any warrantable, defective parts free of charge during this period. We utilize the express services of DHL and TNT Worldwide to deliver parts to you FAST!
