High-Powered Farm Tiller with Blade Rolle and Variable Gear Positions
Product Description
Product Description
Millimeter-level gearbox precision machining technology
Blade shaft rotation three-speed transmission patented technology
High-strength wear-resistant gear
Optional Cultivator Blade
High-strength compression spring
Optional heavy-duty pressing roller
Rotary Tiller Attachment:
* The YAAO tillers are designed with multispeed gearboxes to handle your ever changing conditions. The multispeed gearbox is designed for easy gear access to allow the rotor speed to be changed quickly as you move to different field conditions.
* The machine adopts wide blades to work and clear it can stubble cleaning and rotary tillage simultaneously.
* The quality of the machine is reliable and the performance is excellent. So it can be used on both dry and paddy field and it can reduce the time,labour and cost etc.
* The quality of the machine is reliable and the performance is excellent. So it can be used on both dry and paddy field and it can reduce the time,labour and cost etc.
|
Rotary Tiller Model
|
1GKNB-200G
|
1GKNB-220G
|
1GKNB-230G
|
1GKNB-250G
|
1GKNB-270G
|
1GKNB-300G
|
|
Overall Dimensions (Length × Width × Height) (mm)
|
1230×2230×1400
|
1230×2430×1400
|
1230×2530×1400
|
1260×2750×1400
|
1200×2950×1320
|
1200×3250×1320
|
|
Working Width (cm)
|
200
|
220
|
230
|
250
|
270
|
300
|
|
Total Number of Installed Blades on Blade Roller (pieces)
|
52
|
56
|
60
|
64
|
80
|
88
|
|
Power of Matching Tractor – PS
|
80 – 90
|
75 – 90
|
85 – 100
|
90 – 130
|
90 – 140
|
100 – 160
|
|
Power Take – off Shaft Speed of Matching Tractor (r/min)
|
766
|
540/766
|
540/766
|
540
|
540/766/1000
|
540/766/1000
|
|
Rotary Tiller Blade Model
|
R245 for All
|
|||||
|
Designed Rotational Speed of Blade Roller (r/min)
|
250/280/310 for All
|
|||||
|
Number of Gear Positions of Gearbox (for Variable – speed Rotary Tiller) (pieces)
|
3 for All
|
|||||
|
Plowing Depth (cm)
|
8 – 18 for All
|
|||||
Specification
Rotary Tiller Features:
1. The side adopts gear transmission, which is more powerful. The gear adopts one- time precision for forging forming, and the internal structure is more powerful.
2.. The blades are made of high quality special steel and can be individually replaced or reground with the PTO shaft, equipped with a friction clutch.
3. The height adjustable rear cover of the rotary tiller is providing a smooth finish to the loosened soil and is also an important safety feature.
3. The height adjustable rear cover of the rotary tiller is providing a smooth finish to the loosened soil and is also an important safety feature.
